VIDEO LINK TERADEK BOLT 1000 SDI e HDMI

VIDEO LINK TERADEK BOLT 1000 SDI e HDMI

Transmitter
Video Input 1 x 3G/HD/SD-SDI, BNC (75 Ohms)
1 x HDMI
Video Output 1 x 3G/HD/SD-SDI, BNC (75 Ohms), loop-through out
Channels Number of 20 MHz DFS Channels: 24 (200 MHz channels cannot utilize interlaced, PsF, or 1080p 60/50)
Number of 40 MHz DFS Channels: 11 (USA)
Delay <0.001 sec (when no video format conversion is enabled)
Color Sampling RGB 4:4:4 (HDMI out, 8-bit color)
YCbCr: 4:2:2, 8-bit for SDI (10-bit with no format conversion and FPGA v1.1.0 or later)
Formats 1920 x 1080p 60/59.94/50/30/29.97/25/24/23.98
1920 x 1080PsF 30/29.97/25/24/23.98
1920 x 1080i 60/59.94/50
1280 x 720p 60/59.94/50
576 50 (via HDMI ports only)
480p 59.94 (via HDMI ports only)
576i/480i
NTSC/PAL
Wireless Range: Up to 1000' / 305 m line-of-sight
Non-DFS Frequencies: 5.19 to 5.23 GHz and 5.755 to 5.795 GHz (US) / 5.19 to 5.23 GHz (EU & JP)
DFS Frequencies: 5.27 to 5.55 GHz and 5.67 GHz (US) / 5.27 to 5.67 GHz (EU & JP)
RF Power 22 dBm EIRP (with two 5 dBi TX antennas)
Noise Rejection Can coexist with Wi-Fi and 5 GHz cordless phones
Audio 48 kHz, 24-bit PCM
Mounting 1/4"-20 threaded mounting holes
Power Volts: 7 to 28 VDC
Consumption: 7.5 W
Connector: 2-pin LEMO
Dimensions 0.9 x 2.6 x 4.0" / 2.4 x 6.6 x 10.2 cm
Weight 8 oz / 226.8 g
Receiver
Video Output 1 x 3G/HD/SD-SDI, BNC (75 Ohms)
1 x HDMI
1 x micro-USB 3.0
Delay <0.001 sec (when no video format conversion is enabled)
Color Sampling RGB 4:4:4 (HDMI out, 8-bit color)
YCbCr: 4:2:2, 8-bit for SDI (10-bit with no format conversion and FPGA v1.1.0 or later)
Formats 1920 x 1080p 60/59.94/50/30/29.97/25/24/23.98
1920 x 1080PsF 30/29.97/25/24/23.98
1920 x 1080i 60/59.94/50
1280 x 720p 60/59.94/50
576 50 (via HDMI ports only)
480p 59.94 (via HDMI ports only)
576i/480i
NTSC/PAL
Wireless Range: Up to 1000' / 305 m line-of-sight
Non-DFS Frequencies: 5.19 to 5.23 GHz and 5.755 to 5.795 GHz (US) / 5.19 to 5.23 GHz (EU & JP)
DFS Frequencies: 5.27 to 5.55 GHz and 5.67 GHz (US) / 5.27 to 5.67 GHz (EU & JP)
RF Power 17 dBm EIRP (with one 2 dBi TX antenna)
Noise Rejection Can coexist with Wi-Fi and 5 GHz cordless phones
Audio 48 kHz 24-bit PCM
Power Volts: 7 to 28 VDC
Consumption: 8.5 W
Connector: 2-pin LEMO
Dimensions 5.5 x 3.5 x 0.9" / 13.9 x 8.9 x 2.5 cm
Weight 13.3 oz / 376 g
Packaging Info
Package Weight 6.75 lb
Box Dimensions (LxWxH) 12.8 x 10.9 x 4.8"
Transmit uncompressed 1080p SDI or HDMI video wirelessly over 1000 feet line-of-sight with the Teradek Bolt 1000 SDI/HDMI Wireless Video Transmitter/Receiver Set. Included in this set are a Teradek Bolt 1000 transmitter and receiver, both equipped with 3G-SDI and HDMI ports. The transmitter can pair with and multicast to up to four receivers (additional receivers not included). When transmitting uncompressed video, latencies of less than one millisecond can be achieved if no other video processing is necessary.
Transmitting across the 5 GHz frequency range, the pair utilizes Dynamic Frequency Selection (DFS) to find a clean signal between the transmitter and receiver. This is desirable when working in areas with crowded frequencies. Both transmitter and receiver are equipped with HDMI and SDI ports, which allow for cross conversion from HDMI to SDI and SDI to HDMI during transmission. The transmitter also features a loop-through SDI output. The USB GRAB engine streams the uncompressed video straight out of the receiver and into a personal computer for immediate recording. The included waterproof case with custom-cut foam carries the components during transport and storage.
Transmission Distance
The Bolt 1000 transmitter and receiver pair can transmit 1080p60 video up to 1000' line-of-sight with less than 1 ms of latency when not converting video formats.
Cross Conversion
The transmitter and receiver can cross convert your video signal during transmission.
Durability
The hardened aluminum chassis is designed to withstand the rigors of production, and features 1/4"-20 threaded mounting holes.
USB Grab Engine
The built-in USB port on the receiver enables direct connection to a computer, so you can capture video directly from the receiver into your computer over USB 3.0. With this video available, rough edits can be made even before the footage is offloaded from the camera.
OLED Info Screen
A built-in OLED information screen is built into the receiver. This enables rapid setup and confirmation of your settings.
3D LUT Support
Utilizing the OLED screen, you can apply 3D LUTs with the press of a button. Upload your own LUTs using the free Bolt Manager software, or select from several built-in presets using Bolt's OSD.
20 MHz and 40 MHz Channels
You can select to transmit in 20 or 40 MHz channels. However, please note that while 20 MHz channels allow you to operate more wireless systems at once in a single location and offer a more robust wireless link in challenging RF conditions, they do not support audio transmission, as well as interlaced, PsF, and 1080p 60/50 frame rates. The 40 MHz channels support audio, interlaced, PsF, and 1080p 60/50.
Timecode and Metadata Support
All 3G-SDI Bolt models support metadata, timecode, and start/stop flags from many camera manufacturers, including RED, ARRI, Canon, Sony, and Panasonic.
Dynamic and Manual Frequency Selection
You can select either dynamic or manual frequency.
